AOC
Dual Monitor Arm AM420B - Black

Dual Monitor Arm AM420B - Black

Part Number:
AM420B
Language:
ML
 Without VATWith VAT
Base Price:€106,74€129,16
Total:€106,74€129,16

Introduction

Enhance your workspace: the AM420B dual arm - Seamlessly integrate, maximize space, and manage cables.
The AM420B is an embodiment of precision and strength. Crafted to perfection with an aluminum alloy build, the dual arm accommodates monitor sizes from 17” to 34”, with a maximum weight capacity of 9 kg. Its durable mechanical spring mechanism ensures sturdy support, while VESA compatibility (75x75, 100x100mm) allows for easy integration. Enjoy a versatile range of motion, including up to 495 mm height adjustment, up to 456 mm extension, -15°/90° tilt, -90°/90° swivel, and 360° pivot range, enhancing your workspace flexibility. Select between C Clamp or Grommet installation methods to suit your setup and elevate your ergonomic experience with the dual arm AM420B.

Mounting

Minimum screen size

43.2 cm (17")

Maximum weight capacity

9 kg

Maximum weight capacity (per display)

9 kg

Maximum screen size

86.4 cm (34")

Mounting

Clamp/Bolt-through

Minimum VESA mount

75 x 75 mm

Maximum VESA mount

100 x 100 mm

Panel mounting interface

75 x 75,100 x 100 mm

Number of displays supported

2

Mounting type

Desk

Ergonomics

Depth adjustment range

0 - 455 mm

Tilt angle range

-15 - 90°

Swivelling

Yes

Swivel angle range

-90 - 90°

Pivot angle

0 - 360°

Number of arms

2

Cable management

Yes

Tilt adjustment

Yes

Design

Housing material

Aluminium

Product colour

Black

Weight & dimensions

Weight

4.6 g

Package width

112 mm

Package depth

324 mm

Package height

91 mm

Package weight

5.5 kg

Package type

Box

Packaging content

Clamp included

Yes

Mounting kit

Yes

Manual

Yes

Packaging content

Grommet mount

Packaging data

Quantity per pack

1 pc(s)

Other features

Height (max)

49.5 cm
