Cellular Broadband Adap..cba850 Integrated Lte Advanced Modem Eu

Introduction

- Supports LTE Advanced
- Plug-and-Play Overlay Failover
- Cloud-managed
- Out-of-Band Management
- Power over Ethernet (PoE)

The Cradlepoint ARC CBA850 is a turnkey networking solution for best-in-class 3G/4G/LTE failover that integrates seamlessly with existing network infrastructure.

Using Enterprise Cloud Manager PRIME, the ARC CBA850 provides the ability to extend management capability to any primary router Out-of-Band without a static IP. Equipped with Power-over-Ethernet for flexible, unobtrusive placement anywhere to optimize cellular reception, this powerful solution reduces truck rolls, consolidates infrastructure, and maximizes uptime for businesses that require always-on connectivity.

Defining the industry standard for reliability in cellular routing, the cloud-managed ARC CBA850 empowers administrators to maximize infrastructure investments with a high-speed, automatic secondary path to access and control the network at remote locations when connectivity is lost or even if the primary router goes down.

Benefits

BEST-IN-CLASS BUSINESS CONTINUITY
- Supports LTE Advanced (LP6, LP5 versions only)
- Multi-carrier 4G LTE support with dual SIM capability
- High-speed 4G LTE for the most demanding applications
- Access primary router CLI Out-of-Band to avoid costly truck rolls
- Maximize revenue and protect your brand from downtime

MANAGE REMOTELY
- Robust analytics to manage performance, data, and usage
- Configure, monitor, and manage remotely
- Create real-time alerts to monitor network availability

DEPLOY QUICKLY, SCALE, AND LOWER INSTALLATION COSTS
- SIM-based auto-carrier selection (LP6, LP5, LP4 versions only)
- Increase speed to deployment with “zero-touch” configuration
- Integrates easily with existing infrastructure for turnkey networking failover

SECURE AND PROTECT
- Virtual Server/Port Forwarding, IPv6
- Designed for PCI 3.0 compliant network architectures

Design

Device type

Cellular network gateway

Housing material

Plastic

Ethernet LAN features

Ethernet LAN data rates

10,100,1000 Mbit/s

Supported network protocols

IPv6

Mobile network

Data network

HSPA+,LTE

UMTS bands supported

850,1900 MHz

Number of SIM cards

2

Ports & interfaces

Ethernet LAN (RJ-45) ports

2

Security

IP address filtering

Y

Power

Power consumption (typical)

6 W

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Storage temperature (T-T)

-20 - 70 °C

Operating relative humidity (H-H)

10 - 85%

Storage relative humidity (H-H)

5 - 90%

Weight & dimensions

Dimensions (WxDxH)

122 x 122 x 42 mm

Packaging data

Cables included

LAN (RJ-45)

User guide

Y
