M321 Pg 32 Inch M-series Hard Glass Large Format Display

Introduction

Meticously Powerful Signage with Professional Protection
The NEC MultiSync® M321 PG-2 combines professional protection of your investment with unparalleled display performance. Deliver your message with impact and seamless simplicity for the most convincing results.
Guaranteed reliability even under the toughest conditions is achieved with the super robust 4mm thick protective glass designed to withstanding external impacts. The anti-reflective glass surface combined with brightness levels of 450 cd/m² provides crisp and clear images and readability from different viewing angles and distances.
The MultiSync® M321 PG-2 is the perfect choice for creating a big and durable impression in public spaces with high volumes of people such as for applications in transportation, retail, hospitality and digital out of home as well as for tough environments in industrial applications.

Display

Panel type

IPS

LED backlight

Yes

LED backlighting type

Direct-LED

Display diagonal

81.3 cm (32")

Display technology

LCD

Display resolution

1920 x 1080 pixels

Display brightness

450 cd/m²

HD type

Full HD

Native aspect ratio

16:9

Response time

8 ms

Contrast ratio (typical)

1100:1

Contrast ratio (dynamic)

800:1

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Display number of colours

16.7 million colours

Display diagonal (metric)

81 cm

Horizontal scan range

26 - 91.1 kHz

Vertical scan range

23 - 86 Hz

Native refresh rate

60 Hz

Haze rate

28%

Ports & interfaces

HDMI ports quantity

4

HDMI input ports quantity

4

VGA (D-Sub) input ports

1

DisplayPorts quantity

2

DisplayPorts in

2

USB port

Yes

USB ports quantity

1

USB version

2.0

Ethernet LAN

Yes

Ethernet LAN data rates

100 Mbit/s

Audio (L/R) out

1

Audio

Built-in speaker(s)

Yes

Number of built-in speakers

5

RMS rated power

5 W

Design

Product design

Digital signage flat panel

Product colour

Black

Screen shape

Flat

VESA mounting

Yes

Panel mounting interface

100 x 100,200 x 200 mm

Bezel width (bottom)

2.38 cm

Bezel width (side)

1.44 cm

Bezel width (top)

1.84 cm

Anti-glare screen

Yes

Mounting type

Wall

Performance

Purpose

Universal

Ambient light sensor

Yes

Operating hours (hours/days)

24/7

HDCP

Yes

International Protection (IP) code

IP5X, IP2X

Power

Power consumption (typical)

40 W

Power consumption (standby)

0.5 W

Energy efficiency class (SDR)

G

Energy efficiency class (HDR)

G

Energy consumption (SDR) per 1000 hours

41 kWh

Energy consumption (HDR) per 1000 hours

41 kWh

AC input voltage

100-240 V

Energy efficiency scale

A to G

Computer system

Audio formats supported

MP3

Image formats supported

JPG

Weight & dimensions

Display width

731.5 mm

Display depth

76.5 mm

Display height

438.4 mm

Display weight

9.1 kg

Packaging data

Package width

870 mm

Package depth

160 mm

Package height

527 mm

Package weight

13.2 kg

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

20 - 80%

Storage temperature (T-T)

-20 - 60 °C

Storage relative humidity (H-H)

10 - 90%
