Large Format Display - Multisync M551 Pcap - 55in

Introduction

Superior touch performance for demanding environments
Great first impressions can make all the difference; presenting your business in the best possible way will boost your brand. With a modern, bezel-free styling, 24/7 operation and reduced reflections when ambient light is high, the NEC MultiSync M series PCAP touch engages audiences and facilitates collaboration.

With the powerful Intel Smart Display Module (Intel SDM) computing device, you are primed and ready to provide an exceptional interactive experience to your customers. Perfectly suited to the rigors of public usage, the robust glass surface is resistant to scratches whilst its anti-glare property makes the M series PCAP touch models suitable for use even in areas of high ambient light.

Display

LED backlighting type

Edge-LED

Display diagonal

139.7 cm (55")

Display technology

IPS

Display resolution

3840 x 2160 pixels

Display brightness

500 cd/m²

HD type

4K Ultra HD

Touchscreen

Yes

Touchscreen technology

Projected capacitive system

Number of simultaneous touchpoints

20

Multi-touch

Yes

Native aspect ratio

16:9

Response time

8 ms

Contrast ratio (typical)

8000:1

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Display number of colours

1.07 billion colours

Display diagonal (metric)

138.8 cm

Horizontal scan range

26 - 91.1 kHz

Vertical scan range

23 - 86 Hz

Native refresh rate

60 Hz

Haze rate

5 - 10%

Surface hardness

6

Ports & interfaces

HDMI ports quantity

2

HDMI input ports quantity

2

DisplayPorts quantity

1

DisplayPorts in

1

USB port

Yes

USB ports quantity

1

USB version

2.0

Ethernet LAN

Yes

Ethernet LAN data rates

100 Mbit/s

Number of speaker outputs

1

RS-232 interface

Yes

Audio

Built-in speaker(s)

Yes

Number of built-in speakers

2

RMS rated power

20 W

Design

Product design

Digital signage flat panel

Placement supported

Indoor

Orientation

Horizontal/Vertical

Product colour

Black

VESA mounting

Yes

Panel mounting interface

300 x 300 mm

Performance

Purpose

Universal

Ambient light sensor

Yes

Operating hours (hours/days)

24/7

HDCP

Yes

International Protection (IP) code

IP5X, IP2X

Power

Power consumption (typical)

110 W

Power consumption (standby)

0.5 W

Energy efficiency class (SDR)

G

Energy efficiency class (HDR)

G

Energy consumption (SDR) per 1000 hours

100 kWh

Energy consumption (HDR) per 1000 hours

90 kWh

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Energy efficiency scale

A to G

Weight & dimensions

Display width

1275.8 mm

Display depth

67.8 mm

Display height

746.8 mm

Display weight

36.4 kg

Packaging data

Package width

1430 mm

Package depth

250 mm

Package height

920 mm

Package weight

46.5 kg

Packaging content

Remote control included

Yes

Batteries included

Yes

Cables included

AC, HDMI, USB

Operational conditions

Operating temperature (T-T)

0 - 35 °C

Operating relative humidity (H-H)

20 - 80%

Storage temperature (T-T)

-20 - 60 °C

Storage relative humidity (H-H)

10 - 90%

Logistics data

Harmonized System (HS) code

85285210

Technical details

Sustainability certificates

ENERGY STAR

Compliance certificates

RoHS
