HP 4x1Ex32 KVM IP Console Switch G2 with Virtual Media CAC SW

HP 4x1Ex32 KVM IP Console Switch G2 with Virtual Media CAC SW

Part Number:
AF622A
Language:
UK
 Without VATWith VAT
Base Price:€5.692,26€6.887,64
Total:€5.692,26€6.887,64

Introduction

Do you need a solution that is secure and can manage your servers multiple operating systems remotely?; The HP IP Console Switch G2 with Virtual Media and Common Access Card (CAC) support is a key component in managing the heterogeneous data center and along with the IP Console Viewer software allows remote access to multiple servers running various operating systems. Virtual Media capability allows a removable drive or ISO image to be remotely mapped to an attached server in the data center or a remote office for software installations and upgrades. An intuitive Local Console User Interface provides menus for configuration, virtual media, display, and even security and upgrades from the local console that is the same as the On Board Web Interface (OBWI) used for remote management. The term CAC stands for Common Access Card, also known as "Smart Cards" allows government agencies and other companies to implement two-factor authentication to increase security of their Datacenters.

Performance, Management and Security.
The HP IP Console Switch with Virtual Media capability allows a removable drive or ISO image to be remotely mapped to an attached server in the data center or a remote office for software installations and upgrades. The HP IP Console Switch G2 with Virtual Media offers an intuitive Local Consol User Interface that provides menus for configuration, virtual media, display and even security and upgrades from the local console that is the same as the On Board Web Interface (OBWI) used for remote management. The HP IP Console Switch G2 with Virtual Media comes with a Common Access Card also known as Smart Cards, allows government agencies and others companies to implement two-factor authentication to increase security in the their Datacenters.

Ports & interfaces

Number of computers controlled

32

Video port type

VGA

USB 2.0 ports quantity

4

DC-in jack

Y

Network

Ethernet LAN (RJ-45) ports

1

Performance

Maximum resolution

1600 x 1200 pixels

Number of users

6 user(s)

Design

Product colour

Black

Power

Power consumption (typical)

100 W

Operational conditions

Operating temperature (T-T)

10 - 50 °C

Storage temperature (T-T)

-20 - 70 °C

Operating relative humidity (H-H)

20 - 80%

Storage relative humidity (H-H)

5 - 95%

Weight & dimensions

Width

438 mm

Depth

236.8 mm

Height

43.6 mm

Weight

3.4 kg

Other features

Connectivity technology

Wired

Dimensions (WxDxH)

438 x 236.8 x 43.6 mm

Ports quantity

32

Power requirements

0.25/0.5A

Weight (imperial)

3.45 kg (7.6 lbs)
