ANTEC
Cuprum Strike Csk550 Power Supply Unit 550 W 20+4 Pin ATX ATX Black

Cuprum Strike Csk550 Power Supply Unit 550 W 20+4 Pin ATX ATX Black

Part Number:
0-761345-11741-8
Language:
UK
 Without VATWith VAT
Base Price:€51,22€61,97
Total:€51,22€61,97

Introduction

Antec’s new generation Cuprum Strike Bronze power supply is crafted for quality, efficiency, and performance. Featuring 80 PLUS® BRONZE certification, a quiet 120 mm fan, CSK Bronze includes Antec’s 3 year warranty. The CircuitShield™ suite of industrial-grade protections ensure that the power delivered to your system is safe and reliable in any environment.

80 PLUS® Bronze certified
Delivering up to 88% efficiency, the CSK Bronze Series utilize active PFC, giving you a cooler, quieter system, all powered by Continuous Power.

120 mm Silent Fan
The 120 mm silent fan is ideal for quite computing and is designed for longer lifetime, guaranteeing hours of operation.

Power

Total power

550 W

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Input current

10 - 5 A

Power Factor Correction (PFC) type

Active

Combined power (+3.3V)

110 W

Combined power (+12V)

504 W

Combined power (+5V)

110 W

Combined power (-12V)

3.6 W

Combined power (+5Vsb)

15 W

Max output current (+3.3V)

14 A

Max output current (+12V)

42 A

Max output current (+5V)

16 A

Max output current (-12V)

0.3 A

Max output current (+5Vsb)

3 A

Efficiency

88%

Power protection features

Over power, Over voltage, Overheating, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector

20+4 pin ATX

Motherboard power cable length

55 cm

Number of SATA power connectors

7

SATA power cable length

500,650,800 mm

Peripheral (Molex) power connectors (4-pin)

2

Peripheral (Molex) power cable length

650,800 mm

EPS power connector (4+4 pin)

Y

PCI Express power connectors (6+2 pin)

2

PCI Express power cable length

65 cm

Floppy drive power connector

1

Floppy disk drive cable length

95 cm

Cabling type

Non-Modular

Performance

80 PLUS certification

80 PLUS Bronze

Purpose

PC

Power supply unit (PSU) form factor

ATX

ATX version

2.31

Certification

cTUVus/TUV/CB/RCM/CE/CCC/FCC

Design

Product colour

Black

Cooling type

Active

Fan diameter

12 cm

Number of fans

1 fan(s)

On/off switch

Y

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Weight & dimensions

Width

150 mm

Depth

140 mm

Height

86 mm

Weight

1.53 kg

Packaging data

Package weight

1.71 kg
