Access Point Aircube Airmax Acb-isp Home Wi-Fi With Poe Passthrough Black

Introduction

UNMS Support
Ubiquiti Network Management Software simplifies remote network management.

Super Antenna
Innovative Super Antenna provides wide-area coverage beyond regular Wi-Fi access points.

24V PoE Passthrough
The airCube can be powered by and provide power to an airMAX CPE using 24V PoE.

UMobile Support
Use the intuitive UMobile app for iOS and Android to install and configure airCube.

Sleek Design
The airCube's attractive design means it can be positioned anywhere in the room, improving Wi-Fi performance.

Features

2.4 GHz

Y

5 GHz

N

Maximum data transfer rate

300 Mbit/s

Ethernet LAN data rates

10,100 Mbit/s

Networking standards

IEEE 802.11n

Ports & interfaces

Ethernet LAN (RJ-45) ports

4

USB 2.0 ports quantity

1

USB connector type

Micro-USB

Power

Power over Ethernet (PoE)

Y

Power consumption (max)

5 W

Design

Placement

Floor, Table

Product colour

Black

Housing material

Plastic

LED indicators

Status

Certification

CE,. FCC, IC

Internal

N

Antenna

Antenna gain level (max)

4 dBi

Operational conditions

Operating relative humidity (H-H)

5 - 95%

Operating temperature (T-T)

-10 - 50 °C

Weight & dimensions

Width

87.8 mm

Depth

89.2 mm

Height

89.5 mm

Weight

215 g
