PALO ALTO NETWORKS

Pa Nws Pa5430 Redundant Ac Power Supp

Part Number:
PAN-PA-5430-AC
Language:
UK
Stock:
 Without VATWith VAT
Base Price:€155.722,07€188.423,70
Recupel:+ €0,06+ €0,07
Total:€155.722,13€188.423,77
Add to cart

Introduction

Palo Alto Networks PA-5400 Series ML-Powered NGFWs—comprising the PA-5430, PA-5420, and PA-5410—are ideal for high-speed data center, internet gateway, and service provider deployments. The PA-5400 Series appliances secure all traffic, including encrypted traffic.

The world’s first ML-Powered Next-Generation Firewall (NGFW) enables you to prevent unknown threats, see and secure everything—including the Internet of Things (IoT)— and reduce errors with automatic policy recommendations.

The controlling element of the PA-5400 Series is PAN-OS®, the same software that runs all Palo Alto Networks NGFWs. PAN-OS natively classifies all traffic, inclusive of applications, threats, and content, and then ties that traffic to the user regardless of location or device type. The application, content, and user—in other words, the elements that run your business—then serve as the basis of your security policies, resulting in improved security posture and reduced incident response time.

The PA-5410, PA-5420, and PA-5430 firewalls provide flexibility in performance and redundancy to adapt to your deployment requirements. These models can use either AC or DC power. Dedicated computing and hardware resources ensure predictable performance in networking, security, signature matching, and management functions.

Data transmission

Firewall throughput

80 Gbit/s

HTTP-Proxy throughput

63 Gbit/s

IPSec VPN throughput

42 Gbit/s

Threat protection throughput

60000 Mbit/s

Maximum firewall connections

9000000

Maximum firewall connections per second

380000

Performance

Heat dissipation

1638 BTU/h

Network

Number of VLANs

4094

Security

Security algorithms

3DES, SSH, 128-bit AES, 192-bit AES, 256-bit AES

Ports & interfaces

10G Ethernet (copper) ports quantity

8

10G (fiber) ports quantity

12

40G (fiber) ports quantity

4

Ethernet LAN (RJ-45) ports

8

Ethernet LAN data rates

10,100,1000 Mbit/s

Console port

RJ-45

Number of console ports

1

SFP28 ports quantity

4

Storage

Storage media type

SSD

Total storage capacity

480 GB

Design

Rack mounting

Yes

Form factor

2U

Power

AC input voltage

100-240 V

AC input frequency

50/60 Hz

Power consumption (typical)

630 W

Power consumption (max)

760 W

Power supply

1200 W

Redundant power supply (RPS) support

Yes

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Storage temperature (T-T)

-20 - 70 °C

Operating relative humidity (H-H)

10 - 90%

Operating altitude

0 - 3048 m

Weight & dimensions

Width

440.4 mm

Depth

571.5 mm

Height

87.6 mm
