Wi-Fi Network Printserver 1port USB W/ 10/100 Mbps Ethernet Port

Introduction

Share a standard USB printer with multiple users simultaneously over a wireless network
The PM1115UWEU Wireless-N Print Server lets you share a standard USB printer with multiple users simultaneously over a WiFi network, or a wired LAN connection.
This compact wireless print server supports 802.11b/g/n wireless standards for functionality with almost any wireless network, plus, serving as a primary or backup interface the print server also offers an RJ45 port for 10/100 Mbps wired connections. Providing wireless network printing access enables you to place your printer in any location with network access and avoids the added cost of purchasing individual printers for each workstation or area.
This wireless USB print server can have you up and running in minutes, using either a web-based interface or a Windows® based installation wizard, and also features a WiFi Protected Setup (WPS) button for quick and easy connection to your wireless network. Compatibility with USB 2.0 standards and a wide variety of USB printers and operating systems makes this network print server perfect for installation into mixed environments, with Simple Network Management Protocol (SNMP) support for remote monitoring.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Avoid the added costs of purchasing additional printers with wireless or wired network print sharing
- Convenient setup options with Windows® or web-based configuration
- Broad compatibility for use with most USB printers on the market

Features

Internal

No

Product colour

White

LED indicators

Status, USB, LAN

DHCP client

Yes

Network

Network connection type

Ethernet LAN/Wireless LAN

Networking standards

IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Ethernet LAN data rates

10,100 Mbit/s

Copper ethernet cabling technology

10BASE-T, 100BASE-T

Antenna type

Internal

Protocols

Supported network protocols

SNMP

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

USB 2.0 ports quantity

1

DC-in jack

Yes

Power

AC input voltage

100 - 240 V

Power consumption (typical)

5 W

Input current

0.3 A

AC adapter output voltage

5 V

AC adapter output current

1 A

Software

Server operating systems supported

Windows Server 2003, Windows Server 2008 R2, Windows Server 2016, Windows Server 2012, Windows Server 2019, Windows Server 2022

Windows operating systems supported

Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows Vista,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows Vista x64,Windows XP,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64

Mac compatibility

Y

Mac operating systems supported

Mac OS 9.0, Mac OS 9.1, Mac OS 9.2, Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Linux operating systems supported

Y

Weight & dimensions

Width

58 mm

Depth

72 mm

Height

25 mm

Weight

65 g

Packaging data

Quantity per pack

1 pc(s)

Package weight

319 g

Package width

151 mm

Package depth

230 mm

Package height

70 mm

Packaging content

Quick installation guide

Yes

External power adapter

Yes

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Operating relative humidity (H-H)

0 - 70%

Storage temperature (T-T)

-5 - 65 °C

Storage relative humidity (H-H)

0 - 70%

Technical details

Compliance certificates

RoHS, Trade Agreements Act (TAA), CE, Federal Communications Commission (FCC)

Logistics data

Master (outer) case width

374 mm

Master (outer) case length

492 mm

Master (outer) case height

340 mm

Products per master (outer) case

20 pc(s)
