STARTECH.COM
Firewire Card Adapter 3 Port 2b 1a 1394 Pci-e

Firewire Card Adapter 3 Port 2b 1a 1394 Pci-e

Part Number:
PEX1394B3
Language:
UK
 Without VATWith VAT
Base Price:€78,23€94,66
Recupel:+ €0,06+ €0,07
Total:€78,29€94,73

Introduction

Add 2 native FireWire 800 ports to your computer through a PCI Express expansion slot

This 3 Port PCI Express FireWire adapter card can be installed in a PCI Express slot to add two IEEE1394b (FireWire 800 - 9 pin) ports and one IEEE1394a (FireWire 400 - 6 pin) port, providing broad compatibility with a wide range of FireWire devices (e.g. DV camcorders, external hard drives, digital cameras, etc.).

The 2b, 1a card features a native (single chip) PCI Express chipset - resulting in faster, more reliable and cost effective performance than expansion cards that utilize a "bridge" chip.

The StarTech.com Advantage

- Add 3 FireWire ports to a standard or small form factor (SFF) computer with support for high-powered FireWire devices
- Utilizes a native PCI Express chipset design rather than a bridge chip, ensuring a fast, reliable and cost-effective FireWire expansion
- Backed by a StarTech.com lifetime warranty and free lifetime technical support

Ports & interfaces

Host interface

PCIe

Output interface

Firewire 800 / 400

FireWire 400 ports quantity

1

FireWire 800 ports quantity

2

Design

Internal

Y

Certification

CE, UL, FCC, TAA, REACH

Features

Chipset

Texas Instruments - XIO2213B

Data transfer rate (max)

0.8 Gbit/s

Technical details

Sustainability certificates

RoHS

System requirements

Windows operating systems supported

Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 2000,Windows 2000 Professional,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows 98SE,Windows ME,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows Vista x64,Windows XP,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64

Mac operating systems supported

Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Linux operating systems supported

Y

Server operating systems supported

Windows Server 2003,Windows Server 2008 R2,Windows Server 2012,Windows Server 2016

Weight & dimensions

Width

18 mm

Depth

85 mm

Height

120 mm

Weight

48 g

Packaging data

Quantity

1

Cables included

FireWire

Mounting brackets included

Y

Drivers included

Y

Manual

Y

Package width

148 mm

Package depth

213 mm

Package height

41 mm

Package weight

212 g
