STARTECH.COM
Vga Video Splitter - USB Powered 2 Port

Vga Video Splitter - USB Powered 2 Port

Part Number:
ST122LE
Language:
US
 Without VATWith VAT
Base Price:€28,78€34,83
Recupel:+ €0,06+ €0,07
Total:€28,84€34,90

Introduction

Compact USB-powered VGA splitter allows you to split a video source to two separate displays

This 2-Port VGA Video Splitter allows a computer to display VGA video on two monitors simultaneously.

Perfect for classrooms, tradeshows, or any environment requiring high quality video on several monitors, the ST122LE VGA splitter supports displays with up to 300 MHz of bandwidth and up to 2048x1536 resolution. Plus, to simplify placement of your VGA displays, the splitter features a built-in booster circuit that allows you to locate VGA monitors up to 200 ft away from your system, and can be powered through a USB connection to the host computer, eliminating the need to find an available power outlet.

Application Diagram

The ST122LE VGA Splitter supports easy plug and play installation, and is backed by StarTech.com's 2-year warranty and FREE lifetime tech support.

The StarTech.com Advantage

- USB-Powered VGA video splitter, no bulky external power adapter required
- Multiple screens let you communicate your message more effectively to large audiences with greater impact
- Integrated signal amplifier boosts your connection range to 210 feet (65 meters)

Ports & interfaces

Video port type

VGA

Video out

2x VGA

Video ports quantity

2

Features

Product colour

Black

Housing material

Plastic

Maximum resolution

2048 x 1536 pixels

Maximum operating distance

61 m

Bandwidth

300 MHz

Certification

REACH, CE, FCC, TAA

Power

Output voltage

5 V

Output current

0.5 A

USB powered

Y

Weight & dimensions

Weight

100 g

Packaging data

Package width

145 mm

Package depth

210 mm

Package height

40 mm

Package weight

235 g

Packaging content

Manual

Y

Operational conditions

Operating temperature (T-T)

0 - 70 °C

Storage temperature (T-T)

-20 - 85 °C

Operating relative humidity (H-H)

0 - 95%

Technical details

Connector 1

DB15

Connector 2

DB15

Technical features

DDC, DDC2, DDC2B

Sustainability certificates

RoHS
