2 X 2 Ac Dual-band Wall-mount Poe Access Point

Introduction

2 x 2 AC Dual-Band Wall-Mount PoE Access Point

Powerful 2.4GHz & 5GHz Dual-Band SMB Solution

- 802.11AC Dual-Band High Speed
- Easy Installation
- Designed for High Density Usage
- Multiple SSIDs for Security Management
- Fast Roaming
- Wide Coverage & High Sensitivity
- Seamless Mobility
- Power over Ethernet
- Built-In RADIUS Server
- Business Environments
- Central Management
- Optional Security Cover

The WAP1200 is high-speed, robust wireless solution designed to meet the needs of modern SMBs with the latest IEEE 802.11ac technology for wireless speeds up to 1200Mbps. A wall-mounted design, industrial-grade performance and build quality combined with user-friendly operation, 11ac speeds and an extensive feature set make an ideal dual-band solution for day-to-day enterprise operations.

For businesses that demand security, flexibility and speed – the Edimax Pro series has a wide range of potential applications from office environments to schools, campuses, hotels and hospitals. Multiple SSIDs can be configured for different departments or user groups and a built-in RADIUS server provides additional verification with a scalable AP array architecture for central management of multiple access points. High-density capacity for up to 100 simultaneous users is ideal for BYOD workplaces or other environments with a high volume of users and wireless devices, and fast roaming allows for seamless transitions between multiple access points. Power over Ethernet support (PoE) and an intuitive web-based management interface provide deployment flexibility and extensive management options for company MIS departments and network administrators. An optional security cover also prevents physical theft or tampering, along with a rogue AP detection function to safeguard your network from unauthorized access.

When performance and security are critical for your business, you need products that are engineered for your industry. The Edimax Pro series is designed to help your business and provide the connectivity that you rely on every day, with safety and effectiveness guaranteed.

Features

2.4 GHz

Y

5 GHz

Y

Maximum data transfer rate

1200 Mbit/s

Maximum data transfer rate (5 GHz)

867 Mbit/s

Ethernet LAN data rates

10,100,1000 Mbit/s

Frequency band

2.412 - 2.484, 5.18 - 5.24, 5.26 - 5.32, 5.5 - 5.7, 5.745 - 5.825 GHz

Networking standards

IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11e,IEEE 802.11g,IEEE 802.11n,IEEE 802.1p,IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u

Number of users

100 user(s)

Channels quantity

14 channels

Automatic channel selection

Y

Wi-Fi Multimedia (WMM)/(WME)

Y

VLAN support

Y

Wireless isolation

Y

Quality of Service (QoS) support

Y

Transmitting power

27.5 dBmW

Security

Security algorithms

802.1x RADIUS,EAP-AKA,EAP-FAST,EAP-SIM,PEAP,WEP,WPA,WPA2,WPS

Security features

Wireless STA

MAC address filtering

Y

Number of SSID supported

32

Auto Wireless Distribution System (WDS)

Y

Remote Authentication Dial-In User Service (RADIUS)

Y

VPN support

IPsec, L2TP, PPTP

Protocols

Management protocols

HTTP / HTTPS, SNMP v1/v2c/v3, Telnet, SSH

Management features

Web-based management

Y

Ports & interfaces

Ethernet LAN (RJ-45) ports

2

DC-in jack

Y

Power

Power over Ethernet (PoE)

Y

AC input voltage

12 V

Input current

2.5 A

Power consumption (typical)

12 W

Design

Placement

Table, Wall

Product colour

White

Reset button

Y

LED indicators

Diagnostic, Power

Certification

CE / FCC

Internal

N

Antenna

Antenna features

Detachable antenna

Antennas quantity

2

Antenna gain level (max)

2 dBi

Number of connectors

2

Operational conditions

Operating relative humidity (H-H)

0 - 90%

Operating temperature (T-T)

0 - 50 °C

Storage temperature (T-T)

-20 - 60 °C

Storage relative humidity (H-H)

0 - 90%

Weight & dimensions

Width

183 mm

Depth

183 mm

Height

36 mm

Weight

527 g
