Refurb/intel5218 2.3GHz125w16c22mbdcpddr

Introduction

The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.

Processor

Processor manufacturer

Intel

Processor generation

2nd Generation Intel® Xeon® Scalable

Processor model

5218

Processor base frequency

2.3 GHz

Processor family

Intel® Xeon® Gold

Processor cores

16

Processor socket

LGA 3647 (Socket P)

Component for

Server/workstation

Processor lithography

14 nm

Processor series

Intel Xeon Gold 5000 Series

Processor threads

32

Processor operating modes

64-bit

Processor boost frequency

3.9 GHz

Processor cache

22 MB

Processor cache type

L3

Thermal Design Power (TDP)

125 W

Cooler included

No

Stepping

B1

Bus type

UPI

Processor codename

Cascade Lake

Memory

Maximum internal memory supported by processor

1 TB

Memory types supported by processor

DDR4-SDRAM

Memory clock speeds supported by processor

2667 MHz

Memory channels

Hexa-channel

ECC

Yes

Graphics

On-board graphics card

No

Discrete graphics card

No

Features

Execute Disable Bit

Yes

Market segment

Server

Maximum number of PCI Express lanes

48

PCI Express slots version

3.0

Supported instruction sets

AVX-512

Scalability

4S

Embedded options available

No

Intel® Optane™ Memory module included

Yes

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology)

Yes

Intel® Turbo Boost Technology

2.0

Intel® AES New Instructions (Intel® AES-NI)

Yes

Enhanced Intel SpeedStep Technology

Yes

Intel Trusted Execution Technology

Yes

Intel® Speed Shift Technology

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel TSX-NI

Yes

Intel 64

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Turbo Boost Max Technology 3.0

No

AVX-512 Fused Multiply-Add (FMA) units

1

Intel® vPro™ Platform Eligibility

Yes

Operational conditions

Tcase

87 °C

Technical details

Intel® Run Sure Technology version

Y

Intel® Volume Management Device (VMD) version

Y

Mode-based Execute Control (MBE) version

Y

Number of UPI links

2

Logistics data

Harmonized System (HS) code

85423119
