Catalyst 3560 Switch 48x 10/100/1000 GBit Enet 4x Sfp GBit Enet + Poe With Smi S/w Installed

Introduction

The Cisco® Catalyst® 3560 Series is a line of fixed-configuration, enterprise-class switches that include IEEE 802.3af and Cisco prestandard Power over Ethernet (PoE) functionality in Fast Ethernet and Gigabit Ethernet configurations. The Cisco Catalyst 3560 is an ideal access layer switch for small enterprise LAN access or branch-office environments, combining both 10/100/1000 and PoE configurations for maximum productivity and investment protection while enabling the deployment of new applications such as IP telephony, wireless access, video surveillance, building management systems, and remote video kiosks.

Customers can deploy networkwide intelligent services-such as advanced quality of service (QoS), rate limiting, access control lists (ACLs), multicast management, and high-performance IP routing-while maintaining the simplicity of traditional LAN switching. Available for the Cisco Catalyst 3560 Series at no charge, the Cisco Network Assistant is a centralized management application that simplifies the administration tasks for Cisco switches, routers, and wireless access points. Cisco Network Assistant provides configuration wizards that greatly simplify the implementation of converged networks and intelligent network services.

Features:
- 48 Ethernet 10/100/1000 ports and 4 SFP-based Gigabit Ethernet ports
- 1RU fixed-configuration, multilayer switch
- Enterprise-class intelligent services delivered to the network edge
- IEEE 802.3af and Cisco prestandard Power over Ethernet
- Standard Multilayer Software Image (SMI) installed
- Basic RIP and static routing, upgradable to full dynamic IP routing

Management features

Switch type

Managed

Switch layer

L2

Quality of Service (QoS) support

Y

Web-based management

Y

MIB support

Y

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

48

Gigabit Ethernet (copper) ports quantity

48

SFP/SFP+ slots quantity

4

SFP module slots quantity

4

Network

Networking standards

IEEE 802.1D,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z

10G support

N

Copper ethernet cabling technology

1000Base-T,100Base-TX,10Base-T

Full duplex

Y

IP routing

Y

Flow control support

Y

Link aggregation

Y

Broadcast storm control

Y

Spanning tree protocol

Y

Data transmission

Supported data transfer rates

10/100/1000 Mbps

Switching capacity

32 Gbit/s

MAC address table

12000 entries

Store-and-forward

Y

Maximum data transfer rate

1 Gbit/s

Jumbo frames support

Y

Security

DHCP features

DHCP server

IGMP snooping

Y

Protocols

Management protocols

IGMP, RMON, SNMP, Telnet

Data link protocols

Ethernet, Fast Ethernet, Gigabit Ethernet

Design

Stackable

N

Product colour

Turquoise

Safety

UL 60950, CAN/CSA C22.2, TUV/GS to EN 60950:2000, CB to IEC 60950, NOM-019-SCFI, CE

Certification

FCC 15 A, EN 55022: 1998 (CISPR22), EN 55024: 1998 (CISPR24), VCCI A, AS/NZS 3548 A, CE, CNS 13438 A, MIC

Performance

Internal memory

128 MB

Flash memory

32 MB

Mean time between failures (MTBF)

147000 h

Power

Power consumption (typical)

590 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)

Y

Operational conditions

Operating temperature (T-T)

0 - 45 °C

Storage temperature (T-T)

-25 - 70 °C

Operating relative humidity (H-H)

10 - 85%

Weight & dimensions

Weight

7 kg

Other features

Management platform

Cisco IOS CLI, Cisco Network Assistant, SAA

Dimensions (WxDxH)

445 x 409 x 44 mm

Connectivity technology

Wired

Packet transfer speed

38.7 Mpps

Power requirements

100-240 VAC, 8.0-4.0A, 50-60Hz

Connectivity LEDs

Y
