I-series 3 - 15in - i5-9500te - 16GB Ram - 256GB Flash - Pcap - No Os

Introduction

Modular design. Endless versatility.
Available in sizes ranging from 15 to 24 inches, including with and without stand options, you can easily configure the I-Series to fit the needs of your business - from signage and point-of-sale to self-service, automation controls and more.

Universal VESA Mount
Conveniently mount the I-Series with the built-in VESA mount.

Expand with Edge Connect
Seamlessly attach a variety of peripherals to the edge of the touchscreen.

Reliable, security and performance.
Built with the reliability-tested performance and security of Intel 12th Generation processors, integrated Trusted Platform Modules, Intel vPro™ and the Windows 10 operating system, the I-Series 3 delivers the dependability businesses need.

Enhanced connectivity
for all your accessories.

Support for Linux.
For added flexibility, the I-Series 3 offers no OS models, all pretested with Linux SuSE, Ubuntu and Red Hat operating systems.

Bridge the gap between Windows and Android.
Transitioning to Android in the future? Elo Bridge is the perfect solution. Simply choose the Elo Windows device that fits your needs today, and when you are ready to transition to Android, you can use Elo Bridge to migrate your fleet of devices.

Get peace of mind
with EloCare

Display

Display diagonal

39.6 cm (15.6")

Display resolution

1024 x 768 pixels

Touchscreen

Yes

HD type

XGA

LED backlight

Yes

Touch technology

Multi-touch

Native aspect ratio

4:3

Display brightness

400 cd/m²

Panel type

TFT-LCD

Response time

23 ms

Viewing angle, horizontal

160°

Viewing angle, vertical

150°

Screen shape

Flat

Processor

Processor manufacturer

Intel

Processor family

Intel® Core™ i5

Processor model

i5-1245UL

Processor cores

10

Processor threads

12

Processor boost frequency

4.4 GHz

Processor frequency

4.4 GHz

Performance cores

2

Efficient cores

8

Performance-core Max Turbo Frequency

4.4 GHz

Efficient-core Max Turbo Frequency

2.5 GHz

Processor cache

8 MB

Processor cache type

Smart Cache

Processor base power

15 W

Maximum turbo power

28 W

Memory

Internal memory

16 GB

Internal memory type

DDR5-SDRAM

Maximum internal memory

64 GB

Memory slots

2

Memory slots type

SO-DIMM

Memory clock speed

4800 MHz

Memory layout (slots x size)

1 x 16 GB

Memory form factor

DIMM/SO-DIMM

Storage

Total storage capacity

256 GB

Storage media

SSD

Number of storage drives installed

1

Number of storage drives supported

1

Total SSDs capacity

256 GB

Number of SSDs installed

1

SSD capacity

256 GB

SSD interface

M.2

NVMe

Yes

SSD form factor

M.2

Optical drive type

No

Graphics

Discrete graphics card

No

Discrete graphics card model

Not available

On-board graphics card

Yes

On-board GPU manufacturer

Intel

On-board graphics card family

Intel Iris Xe Graphics

On-board graphics card model

Intel Iris Xe Graphics

Audio

Built-in speaker(s)

Yes

Number of speakers

2

RMS rated power

4 W

Camera

Built-in camera

No

Network

Wi-Fi

Yes

Top Wi-Fi standard

Wi-Fi 6 (802.11ax)

Wi-Fi standards

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

Ethernet LAN

Yes

Ethernet LAN data rates

10,100,1000 Mbit/s

Bluetooth

Yes

Bluetooth version

5.3

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

4

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

1

Headphone outputs

1

Design

Product colour

Black

Wall mountable

Yes

VESA mounting

Yes

Panel mounting interface

75 x 75 mm

Performance

Product type

All-in-One PC

Market positioning

Business

Trusted Platform Module (TPM)

Yes

Trusted Platform Module (TPM) version

2.0

Software

Operating system installed

No

Power

AC adapter power

180 W

AC adapter frequency

50 - 60 Hz

AC adapter input voltage

100 - 240 V

AC adapter output voltage

24 V

Power consumption (standby)

5 W

Power consumption (off)

0.5 W

Weight & dimensions

Width (with stand)

359.5 mm

Depth (with stand)

356 mm

Height (with stand)

197.5 mm

Weight (with stand)

6.7 kg

Package width

497 mm

Package depth

487 mm

Package height

345 mm

Package weight

10.3 kg

Operational conditions

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

20 - 80%

Storage relative humidity (H-H)

5 - 95%

Certificates

Compliance certificates

CB, CCC, Federal Communications Commission (FCC), Norma Oficial Mexicana (NOM), RCM, RoHS, State Radio Regulation of China (SRRC), UKCA, VCCI, CE, Industry Canada (IC)

Sustainability

Sustainability certificates

ENERGY STAR

Packaging content

Quick start guide

Yes

Cables included

AC

Power cord included

Yes

Other features

Mean time between failures (MTBF)

50000 h
