APC
Rack Pdu Basic 1u 22kw 230v (6) C19

Rack Pdu Basic 1u 22kw 230v (6) C19

Part Number:
AP7526
Language:
UK
 Without VATWith VAT
Base Price:€902,85€1.092,45
Recupel:+ €0,07+ €0,08
Total:€902,92€1.092,54

Introduction

Features:
-High Power Density.
-Horizontal mounting capability.
-Low Cost Power Distribution.

Design

PDU types

Basic

Rack capacity

1U

Mounting

Horizontal

Product colour

Black

Ports & interfaces

AC outlets quantity

6 AC outlet(s)

AC outlet types

C19 coupler

Input connection type

IEC 309 32A 3P+N+PE

Output connections

IEC 320 C19

Features

Cable length

2.44 m

Certification

CE,GOST,VDE

Power

Nominal input voltage

400 V

Nominal output voltage

230 V

Load capacity

22080 VA

Maximum input current per phase

32 A

Maximum total current draw per phase

32 A

Maximum power

22080 W

Weight & dimensions

Dimensions (WxDxH)

437 x 254 x 44 mm

Weight

4.84 kg

Packaging data

Package dimensions (WxDxH)

559 x 502 x 241 mm

Package weight

6.98 kg

Operational conditions

Operating temperature (T-T)

-5 - 45 C

Storage temperature (T-T)

-25 - 65 C

Operating relative humidity (H-H)

5 - 95%

Storage relative humidity (H-H)

5 - 95%
